Transmission Distance 10km 40Gb/s QSFP LR4 Optical Transceiver 1277.5nm 10km Duplex LC for Speed Fiber Optic Equipment

Name: Transmission Distance 10km 40Gbs QSFP LR4 Optical Transceiver 12775nm 10km Duplex LC for Speed Fiber Optic Equipment
Brand: Starsurge
Price: 1 USD

Quality Transmission Distance 10km 40Gb/s QSFP LR4 Optical Transceiver 1277.5nm 10km Duplex LC for Speed Fiber Optic Equipment wholesale

Model Number : CC-QJJCC1L-SD

Place of Origin : China

Brand Name : Starsurge

Price : Negotiable

Certification : RoHS CE FCC UL

MOQ : 1 pc

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 10000pcs/month

Delivery Time : 2-7days

Packaging Details : carton

Type : Optical Transceiver

Use : Data Center Backbone, High-Speed Servers, SAN, Rou

Warranty Time : 1 year

Network : Ethernet, Infiniband

Port : QSFP+

Power Source : +3.3V ±5%

Connector Type : LC Duplex

Power - Minimum Receivable : ≤ 1.5W

Transmission Distance : 10km

Data Rate : 40Gbps

Wavelength : CWDM (1271nm, 1291nm, 1311nm, 1331nm)

Compliance Standard : IEEE 802.3ba 40GBASE-LR4

Features : Uncooled 4x10Gb/s CWDM Transmitter, Supports Infiniband SDR, DDR, QDR

Cable Type : Single-mode Fiber (SMF)

Material : Metal + Plastic

Contact Now

Transmission Distance 10km 40Gb/s QSFP LR4 Optical Transceiver 1277.5nm 10km Duplex LC for Speed Fiber Optic Equipment

40Gb/s QSFP+ LR4 Optical Transceiver CC-QJJCC1L-SD

This product is a transceiver module designed for 10km optical communication applications. The design is compliant to 40GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 inputs channels (ch) of 10Gb/s elec trical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data.

Applications

Data Center Backbone

Ethernet Switches

High-speed Servers

High-performance Computing Clusters

SAN, Routers, Hubs, Load Balancer

Features

Compliant with 40G Ethernet IEEE 802.3ba 40GBASE LR4 standards

Uncooled 4x10Gb/s CWDM transmitter

Supports Infiniband SDR, DDR and QDR

Wide Operating Temperature(0°C~70°C)

Our company is a professional network solution supplier. Based on the information industry, it integrates the research and development of computer network technology and system integration, and provides users with a full range of technical services such as network platforms, system platforms, and application platforms. Show users the solutions of various new network systems and application systems. Our clients cover industries such as government, finance, telecommunications, colleges, transportation,enterprises, hospitals, securities, and public services. The main products include Mellanox, Ruckus,Aruba,Extreme, etc. with favorable prices, rich product catalogs, and perfect after-sales services, the business continues to expand, and customers are all over the United States, South Africa, Europe, East Asia, Russia, and Australia And South America and other countries in the world, has accumulated rich experience in export and customer service. Always to the concept of"quality-oriented, service-oriented", and provide you with cost-effective products and solutions with high-quality professional standards, dedicated attitude and efficient service system. We are committed to building an ecological platform to contribute to the development of information technology!

Q1.What can you buy from us?

Mellanox, Aruba, Starsurge, Rukus, Extreme brand products, including switches, network cards, cables, modules,AccessPoint, etc.

Q2.How about the delivery date?

It usually takes 3-5 working days. For specific models, please contact us to check thestock. In the end, the actual consultation shall prevail. We will do our best to deliver as soon as possible.

Q3.What's your warranty terms?

We supply 12 months warranty time.

Q4.How about the Shipping Method?

We use Fedex/DHL/UPS/TNT and other air shipments,sea shipments are also workable. In one words, we could do any shipments that you wanted.

Q5.Can I get some samples?

Yes, sample order is available for quality check and market test. You only need to pay the sample cost and express cost.

Q6.What are your core strengths?

First-hand supply, Original and new products with the favorable price and perfect after-sales service

Q7.Price questions

The inventory turnover is fast, and the cost of each batch of goods fluctuates according to the market price. The final price is subject to the sales quotation. Please understand.

Transmission Distance 10km 40Gb/s QSFP LR4 Optical Transceiver 1277.5nm 10km Duplex LC for Speed Fiber Optic Equipment Images
