10G SFP Module Ethernet Fiber Optical Transceiver 80km 11.3Gbps Time 1 year Data Rate Up to 11.3Gbps

Name: 10G SFP Module Ethernet Fiber Optical Transceiver 80km 113Gbps Time 1 year Data Rate Up to 113Gbps
Brand: Starsurge
Price: 1 USD

Quality 10G SFP Module Ethernet Fiber Optical Transceiver 80km 11.3Gbps Time 1 year Data Rate Up to 11.3Gbps wholesale

Model Number : CC-PII448L-xD

Place of Origin : China

Brand Name : Starsurge

Certification : RoHS CE FCC UL

Price : Negotiable

MOQ : 1 pc

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000pcs/month

Delivery Time : 2-7days

Packaging Details : carton

Type : Optical Transceiver

Use : network

Warranty Time : 1 year

Network : 10G Ethernet

Power Source : AC 220V

Connector Type : LC

Power - Minimum Receivable : 3.3v

Frequency Range : 0-1

Product name : CC-PII448L-xD

Material : Metal Housing

Application : 10G Ethernet

Cable Type : Single Mode Fiber (SMF)

Receiver : APD (Avalanche Photodiode)

Reach : Up to 80km over SMF

Data Rate : Up to 11.3Gbps

Contact Now

10Gb/s 80km SFP+ Optical Transceiver Module CC-PII448L-xD

This 1550nm cooled EML 10Gbps SFP+ transceiver is designed to transmit and receive optical data in 10G Ethernet links over single mode optical fiber up to 80km. The SFP+ 80km module electrical interface is compliantto SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled. The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI.

Standards

• SFF-8431/SFF-8472

• SFF-8432

Applications

•10G Ethernet

• 8.5G/10G Fiber Channel

• 10G SONET/SDH, OTU2/2e

Features

• Hot Pluggable

• LC Duplex optical interface

• 1550nm cooled EML transmitter, APD receiver

• Support up to 11.3G bit rates

• Low power consumption<2w

•Up to 80km SMF length

• All-metal housing for superior EMI performance

• Cost effective SFP+ solution, enables higher port densities and greater bandwidth

• RoHS compliant (lead free)

• Operating case temperature Commercial: 0 to 70 °C Industrial: -40 to 85 °C
